Description
Pallet Racking has been tested to and fully complies with latest Australian racking code AS 4084-2012
Below are the standard frame heights available from our stock. Please note that special sizes can be made and ordered upon request
| Frame Height | Frame Depth | Post Section available from stock |
| 914mmH | 609/838/1219mm | 90A |
| 1829mmH | 609/838/1219mm | 90A |
| 2438mmH | 609/838/1219mm | 90A |
| 3658mmH | 609/838/1219mm | 90A |
| 4267mmH | 609/838/1219mm | 90A |
| 4877mmH | 609/838/1219mm | 90A/90B |
| 6096mmH | 609/838/1219mm | 90A/90B |
| 6704mmH | 609/838/1219mm | 90B |
| 7315mmH | 609/838/1219mm | 90B/90C |
Below are standard beams available from our stock. Please note that special sizes can be made ordered upon request
| Beam Length | Beam Section | Connector type |
| 1372mmL | Step60x40Box80x40mm | 2pin3pin |
| 1524mmL | Box80x40mm | 3pin |
| 1829mmL | Box80x40mm | 3pin |
| 2133mmL | Box80x40mm | 3pin |
| 2438mmL | Box80x40mm | 3pin |
| 2591mmL | Step60x40Box80x40mm
Box100x50mm Box120x50mm |
2pin3pin
3pin 4pin |
| 2743mmL | Step60x40Box80x40mm
Box100x50mm Box120x50mm |
2pin3pin
3pin 4pin |
| 3048mmL | Box110x50mm | 3pin |
| 3350mmL | Box120x50mm | 4pin |
| 3658mmL | Box130x50mm | 4pin |
| 3810mmL | Box130x50mm | 4pin |
| 4267mmL | Box150x50mm | 4pin |
